| Manufacturer | Innolux |
| Model Name | G070Y3-T01 |
| Screen Size | 7.0 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 156.0 x 82.8 (H×V) |
| Outline(mm) | 168.0 x 94.0 x 6.35 (H×V×D) |
| Pixel Pitch(mm) | 0.1950 x 0.1725 (H×V) |
| Treatment | Hard Coating ( 3H ), AG ( Haze 25 % ) |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 650 : 1 (Typ.) (TM) |
| Viewing Angle | R/L/U/D 70/70/60/60 (CR≥10) |
| Response | 5/11 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 262K , 60% NTSC |
| Backlight | WLED , 30K hours , without Driver |
| Net Weight | 180g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 6-bit) , 50 pins , FPC |
| Voltage Supply | +3.3 V |
| Max. Ratings | Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package | Innolux Original package; 40 pcs/ctn; weight : 15.5Kgs; size : 435(L)mm x 350(W)mm x 265(H)mm |
