| Model: | RP240160A |
| Dots: | 240 x 160 |
| LCM Type | COG |
| Module Size | 85.0*62.8*2.0mm |
| Viewing Area | 77.58*51.6mm |
| Active Area | 71.98*47.98mm |
| Dot Pitch | 0.41 x 0.41 mm |
| Dot Size(W*Hmm) | 0.36 x 0.36 mm |
| Controller | ST7686S |
| LCD Type | FSTN,STN BLUE/Y-G |
| Operating Voltage | 3V |
| Backlight | LED |
| Operating Temperature | -20 ~ +70ºC |
| Storage Temperature | -30 ~ +80ºC |
